Tractor Hydraulic Requirements @ 2350 psi
Configuration Rows Requirements Description
Base Machine with Ground Contact Drive / RU Hoppers /
Vacuum Meters with PTO pump
PTO Hydraulic pump supplies oil flow for vacuum
hydraulic circuit.
 Add 4 GPM when using centrifugal fertilizer pump
option.
External case drain required.
12R
3 SCV 28 gpm
#1 SCV: Planter Lift (red label)
#2 SCV: Markers/Fold (blue label)
#3 SCV: Weight Distribution (yellow label)
16R
24R
Base Machine with Ground Contact Drive / RU Hoppers /
Vacuum Meters without PTO pump

Add 4 GPM when using centrifugal fertilizer pump
option.
External case drain required.
12R
5 SCV
43 gpm #1 SCV: Planter Lift (red label)
#2 SCV: Markers/Fold (blue label)
#3 SCV: Weight Distribution (yellow label)
#4 and #5 SCV: Vaccum (PTO) (green
label)
16R
44 gpm
24R 5 SCV 45 gpm
Base Machine with Hydraulic Drive / RU Hoppers /
Vacuum Meters with PTO pump
PTO Hydraulic pump supplies oil flow for vacuum
hydraulic circuit.
Add 4 GPM when using centrifugal fertilizer pump
option.
External case drain required.
12R
4 SCV 36 gpm
#1 SCV: Planter Lift (red label)
#2 SCV: Markers/Fold (blue label)
#3 SCV: Weight Distribution (yellow label)
#4 SCV: Power Pack/Hydraulic Drive
(black label)
16R
24R
Base Machine with Hydraulic Drive / RU Hoppers /
Vacuum Meters without PTO pump

Add 4 GPM when using centrifugal fertilizer pump
option.
External case drain required.
12R
6 SCV
51 gpm
#1 SCV: Planter Lift (red label)
#2 SCV: Markers/Fold (blue label)
#3 SCV: Weight Distribution (yellow label)
#4 SCV: Power Pack/Hydraulic Drive
(black label)
#5 and #6 SCV: Vaccum (PTO) (green
label)
16R 52 gpm
24R 53 gpm
Base Machine with Hydraulic Drive / RU Hoppers /
Vacuum Meters / True Depth (hydraulic down force) with
PTO pump
PTO Hydraulic pump supplies oil flow for vacuum
hydraulic circuit.

Add 4 GPM when using centrifugal fertilizer pump
option.
External case drain required.
16R 4 SCV 40 gpm
#1 SCV: Planter Lift (red label)
#2 SCV: Markers/Fold (blue label)
#3 SCV: Weight Distribution/True Depth
(Hydraulic Down Force) (yellow
label)
#4 SCV: Power Pack/Hydraulic Drive
(black label)
24R 4 SCV 40 gpm
Continued on next page.
