Model 4900M0290-01
Rev. 8/19 1-9
Tractor Hydraulic Requirements @ 2350 psi
Configuration Rows Requirements Description
Base Machine with Hydraulic Drive / RU Hoppers /
Vacuum Meters / True Depth without PTO pump
Add 4 GPM when using centrifugal fertilizer pump
option.
External case drain required.
16R
6 SCV 56 gpm
#1 SCV: Planter Lift (red label)
#2 SCV: Markers/Fold (blue label)
#3 SCV: Weight Distribution/True Depth
(Hydraulic Down Force) (yellow label)
#4 SCV: Power Pack/Hydraulic Drive
(black label)
#5 and #6 SCV: Vaccum (PTO) (green
label)
24R
Base Machine with Ground Contact Drive / Bulk Fill /
Vacuum Meters with PTO pump
PTO Hydraulic pump supplies oil flow for vacuum
hydraulic circuit.
Add 4 GPM when using centrifugal fertilizer pump
option.
External case drain required.
12R
3 SCV
34 gpm
#1 SCV: Planter Lift (red label)
#2 SCV: Markers/Fold (blue label)
#3 SCV: Weight Distribution/Bulk Fill
(yellow label)
16R 35 gpm
24R 36 gpm
Base Machine with Ground Contact Drive / Bulk Fill /
Vacuum Meters without PTO pump
Add 4 GPM when using centrifugal fertilizer pump
option.
External case drain required.
12R
6 SCV
49 gpm
#1 SCV: Planter Lift (red label)
#2 SCV: Markers/Fold (blue label)
#3 SCV: Weight Distribution/Bulk Fill
(yellow label)
#4 SCV: Power Pack/Hydraulic Drive
(black label)
#5 and #6 SCV: Vaccum (PTO) (green label)
16R 51 gpm
24R 53 gpm
Base Machine with Blue Drive or Hydraulic Drive / Bulk Fill
/ Vacuum Meters with PTO pump
PTO Hydraulic pump supplies oil flow for vacuum
hydraulic circuit.
Add 4 GPM when using centrifugal fertilizer pump
option.
External case drain required.
12R
4 SCV
42 gpm
#1 SCV: Planter Lift (red label)
#2 SCV: Markers/Fold (blue label)
#3 SCV: Weight Distribution/Bulk Fil
(yellow label)
#4 SCV: Power Pack/Hydraulic Drive
(black label)
16R 43 gpm
24R 44 gpm
Base Machine with Blue Drive or Hydraulic Drive / Bulk Fill
/ Vacuum Meters without PTO pump
Add 4 GPM when using centrifugal fertilizer pump
option.
External case drain required.
12R
6 SCV
57 gpm
#1 SCV: Planter Lift (red label)
#2 SCV: Markers/Fold (blue label)
#3 SCV: Weight Distribution/Bulk Fill
(yellow label)
#4 SCV: Power Pack/Hydraulic Drive
(black label)
#5 and #6 SCV: Vaccum (PTO) (green label)
16R 59 gpm
24R 61 gpm
Base Machine with Blue Drive or Hydraulic / Bulk Fill /
Vacuum Meters / True Depth with PTO pump
PTO Hydraulic pump supplies oil flow for vacuum
hydraulic circuit.
Add 4 GPM when using centrifugal fertilizer pump
option.
External case drain required.
16R
4 SCV
47 gpm
#1 SCV: Planter Lift (red label)
#2 SCV: Markers/Fold (blue label)
#3 SCV: Weight Distribution/Bulk Fill
(yellow label)
#4 SCV: Power Pack/Hydraulic Drive/
True Depth (Hydraulic Down Force)
(black label)
24R 52 gpm
Notes:
All SCVs should be set to max flow at all times wih the exception of the bulk fill circuit on mechanical 4900
Tractor RPMs not recommended below 1750 RPMs
Consult your tractor manufacturer to ensure proper connection, hydraulic flow, pressure and heat
dissipation
Power beyond will reduce the number of SCVs by 1. Not recommended - Kinze suggests that if power
beyond must be used, only the bulk fill circuit be connected using all three connections (Pressure, Return,
Load Sens). Consult your tractor manufacturer for recommendations.
PTO pump is required for all machines equipped with Bulk Fill, Vacuum & Blue Drive
