H11O608A
4. Pull out the oil dipstick, clean it,
and then insert it into its original
position. Then, pull it out again and
check if the fuel level is within the
specied range.
5. If the oil level is too low, add some
new oil so that the level is within
the allowable range.
(1) Oil Dipstick
(A) Upper Limit (B) Lower Limit
1. Check the engine oil daily.
2. Park the tractor on a level ground
and lower the implement.
3. If the engine was just running,
wait for approx. 5 seconds before
checking the oil level.
U26O707A
(1) Oil Inlet Plug (2) Gauge
(A) Oil Level is Acceptable Within This Range
-
CAUTION
-
needed.
-
To Next Page
