ITEM DS3510 REMARKS
Engine
Model 3A165LWD
Number of cylinders 3
Total displacement cc (cu) 100.5 (1,647)
Bore and stroke in. (mm) 3.4 x 3.6 (87 x 92.4)
Engine gross power HP (kw) 34 (25.4)
P.T.O Power HP (kw) 27.6 (20.6)
Rated revolution rpm 2,600
Capacities
Fuel tank U.S.gal. (L) 7.9 (30)
Transmission oil U.S.gal. (L) 6.87 (26.0)
Front axle oil U.S.gal. (L) 1.19 (4.5)
Drive train
Clutch Dual clutch
Transmission
Shuttle Constant mesh
Main Synchronized mesh, 4
Range Constant mesh, 2
Speed 8 x 8
Ground speed
(Tire for agricultural)
Forward
mile/h (Km/h)
0.81~11.66 (1.30~18.80)
Reverse
mile/h (Km/h)
0.74~10.64 (1.19~17.14)
Brake
Traveling Wet disc type
Parking Connected with the traveling brake
Differential lock Standard for rear axle
GENERAL SPECIFICATIONS
