Attach only required amount
of weight.
The life of the axle or wheel
can be shortened.
IMPORTANT
Additional weight might be
needed for transporting heavy
implements.
Reduce the speed regardless
of additional weight when driv-
ing on a bumpy or rough road
with the implement lifted. The
tractor can roll over.
CAUTION
Model Max. load
DS3510 149.6 lbs. (17 kg x 5 Pieces)
If the front tires are heavily loaded,
it becomes hard to steer the tractor,
the tires can be worn faster and the
durability of the front axle can be de-
teriorated.
H11O4D4A
(1) Front Bracket
(2) Spring Washer
(3) Bolt
(4) Nut
(5) Balance Weight
(6) Bolt
(7) Spring Washer
(8) Nut
(9) Front Weight Bolt
(10) Nut
(11) Spring Washer
(12) Plain Washer
COMPONENTS FOR ADDITIONAL FRONT WEIGHT (OPTION)
Wh e n i n s t a l l i n g or r e m o v i n g a
weight, always check the tire ination
pressure and adjust it as necessary.
The front weights are available at the
KIOTI Dealer.
For required number
of weights, consult your local KIOTI
Dealer.
