Make sure to interlock the
brake pedals, as an accident
such as rollover or impact can
occur during driving on the
road at high speed.
The durability of the axle can
be deteriorated if only one
brake pedal is depressed while
the 4 WD i s ac tivat ed . It i s
more effective to use the quick
turn function, rather than the
brake (one side) pedal, while
the 4WD is activated and to
use the brake (one side) pedal
while the quick turn function
is activated.
•
•
WARNING
STEERING WHEEL ADJUSTMENT
The angle of the steering wheel can
be adjusted for the driver’s comfort.
Hold the steering wheel with both
hands, depress the tilt pedal lightly
and then adjust the position of the
steering wheel as desired.
(1) Steering Wheel Tilt Pedal
(A) Lowering (B) Lifting
Tf1O438A
Do not adjust the tilt steering
while driving. An accident can
occur unexpectedly.
•
CAUTION
BRAKE PEDAL
1. Make sure to link the left and right
brake pedals as shown in the gure
while driving on a road. The tractor
can roll over if depressing only one
brake pedal at a high speed.
2. To make a sharp turn in a work eld,
disengage the left and right brake
pedals to use one brake pedal. Un-
lock the brake lock, and then turn
the steering wheel while depressing
the brake pedal on the turning side.
(1) Brake Pedal (L) (2) Brake Pedal (R)
(3) Pedal Interlock
(A) Unlock (B) Lock
Tf1O437A
