The bulb and capacity used in this
tractor are listed in the below table.
No. Bulb
1 Head Lamp 55W/55W
2 Position Lamp (Front) 5W
3 Stop/position Lamp (Rear) 21W/5W
4 Turn Signal Lamp 21W
5 Work Lamp 35W
6
Cluster
Indicator
Charging
Warning Light
3W
Others 1.4W
7 Backup Lamp 21W
Main Fuse
60A
blow fuse can damage elec-
trical systems in the tractor
severely.
-
or contact your local KIOTI
-
lems.
•
•
(1) Handle
(A) Pull (B) Open
1. Turn the key switch to the "OFF"
position and open the hood.
T11O745A
The main fuse is to protect electric
devices and wirings. If the ignition,
preheat, charge or main function is
faulty, nd and remove the fault and
replace the fuse with a new one.
