3. Replace the damaged belt.
(1) Net (2) Condenser
(3) Oil Cooler
CLEANING AIR CONDITIONER
CONDENSER (AB)
1. Pull the hood lever on the right
side forward to open the hood.
2. Undo the wing bolt and pull the
grill to the right side to remove it.
Remove the oil cooler as neces-
sary to clean the condenser.
when checking. If cooler fan is
blocked by dirt, clean with a soft
brush or cloth using water.
•
CAUTION
T11O719A
(AC)
(1) Adjusting Bolt (2) Lock Nut
T11O741A
If the front axle pivot pin adjustment
is not correct, front wheel vibration
can occur causing vibration in the
steering wheel
Loosen the lock nut, tighten the ad-
justing screw all the way, and then
loosen the screw by 1/6 turn. Re-
tighten the lock nut.
CAUTION
-
ing air conditioner belt.
•
