T11O452A
POSITION CONTROL LEVER
(1) Position Control Lever (2) Lock Bolt
(3) Lower Link
(A) Lifting (B) Lowering
The position control lever is used to
adjust the height of implements on
the 3-point hitch ends.
The implement attached to the lifting
arm can be lowered by pushing the
lever while the implement is raised
by pulling the lever.
In order to limit the lowering height of
implements, use the lock bolt (2) to
limit the operating range of the lever.
For detailed information, refer to
"3 point hitch control" in Chapter 5.
Make sure that the seat belt
is not twisted. It cannot work
properly, leading to a hazard-
ous condition.
The seat belt should go around
your body as low as possible,
not your waist or abdomen.
Otherwise, the seat belt cannot
protect you properly.
WARNING
