(1) Element (2) Cap
(3) Evacuator Valve
1. The air cleaner uses a dry ele-
ment. Never apply oil.
2. Dust should not accumulate in the
dust cap or element. Remove and
clean the dust cap and the ele-
ment every week. If the tractor is
operated in extremely dusty condi-
tions, daily inspection is required.
3. Do not touch the filter element
except in cases where cleaning is
required.
20 ~ 30 mm (0.8 ~ 1.2 in.)
T11O711A
2. To adjust the play, unscrew the
lock nut and adjust the clutch cable
3. After setting the play properly,
tighten the lock nut rmly.
its function if it is correctly and
maintained air cleaner will
-
tion in engine life.
-
ter element removed.
the arrow (on the rear of
-
will not function and dust will
adhere to the element.
4. When cleaning the element, refer
to the instructions that follow.
To clean the element, use only clean
dry compressed air on the inside of
the element. Air pressure at the nozzle
must not exceed 29 psi (2 kgf/cm²).
Maintain reasonable distance between
the nozzle and the lter.
