Kioti RX8030 - Lubricating Grease Locations (O)

7
-
20
RX6030 / RX7030 / RX8030
Apply high-quality multi-purpose grease onto the positions in the gure at every 50 hours of operation or whenever nec-
essary.
LUBRICATING GREASE LOCATIONS (O)
(1) Front axle support bracket (FRT)
(2) Front axle case support (LH)
(1) Front axle support bracket (RR)
(2) Front axle case support (RH)
(1) Brake shaft (RH)
M55O766A M55O7B3A M55O7B4A
(1) Brake shaft (LH)
T11O738A
T11O739A
(1) Pitman arm support
M55O7B5A
(1) Hydraulic cylinder (upper/lower)
(2) Top link (upper/lower) (3) Lift rod (LH/RH)
