GENERAL SPECIFICATIONS
[MANUAL]
ITEM RX6030C RX6030 RX7030 RX8030C RX8030
Engine
Model 4B243DTM 4F243DTM 4FT-TM2
Number of cylinders 4
Total displacement cc(cu in. ) 2,435 (148.6)
Bore and stroke mm (in.) 87 x 102.4 (3.4 x 4.0)
Engine gross power kw (HP) 44.7 (60) 49.2 (66) 54.4 (73)
PTO Power kw (HP) 39 (52.3) 43 (57.6) 49 (65.5)
Rated revolution rpm 2,600
Capacities
Fuel tank L (U.S.gal) 95 (25.1) 85 (22.5) 95 (25.1) 85 (22.5)
Engine Oil (with Filter) L (U.S.gal)
7.7 (2.03) 9.0 (2.38)
Transmission oil L (U.S.gal) 60 (15.9)
Front axle oil L (U.S.gal) 8.5 (2.2)
Drive train
Clutch Dry Single Plate
Hydro Multi Wet Disc
Dry Single
Plate
Transmission
Shuttle Synchro Shuttle
Main
Synchro mesh
4 stages
Range
Constant mesh
6 stages
Speeds 24 X 24
