6. Front distance should be 2~8 mm
less than rear distance. If not, ad-
just the tie rod length.
READJUSTMENT
(1) Tie Rod Lock Nut (2) Tie Rod
1. Loosen the lock nut and turn the
turnbuckle to adjust the rod length
until the proper toe-in measure-
ment is obtained.
2. Check the toe-in value after the tie
rod is adjusted.
3. Adjust it again if necessary.
M55O782A
Check to ensure the radiator hoses
are free from damage and are tight-
ened properly every 200 hours or ev-
ery 6 months, whichever comes rst.
1. If the hose clamps are loose or
water leaks from hose, tighten
clamps securely.
2. If the radiator hoses are swollen,
hardened, cracked, or otherwise
damaged, you must replace the
hoses. Failure to do so could lead
to coolant loss and engine damage.
(1) Clamp (2) Hose
M55O783A
CHECKING RADIATOR HOSE
