COMPONENTS FOR ADDITIONAL FRONT WEIGHT
(1) Front-end Weight
(2) Retaining Pin
(3) Front Weight Mounting Bolt
(4) Front Weight Bolt
(5) Nut
A40O4D4A-1
When installing or removing a weight,
always check the tire inflation pres-
sure and adjust it as necessary.
The front weights are available at the
KIOTI Dealer. For required number
of weights, consult your local KIOTI
Dealer.
A t t ac h o n l y t he r e q ui r e d
amount of weight. Otherwise,
the life of the axle or wheel
can be shortened.
•
IMPORTANT
Additional weight might be
needed for transporting heavy
implements.
Reduce the speed regardless
of additional weight when driv-
ing on a bumpy or rough road
with the implement lifted. The
tractor can roll over.
•
•
CAUTION
H11O4E1A
(1) Rear Weight
ADDITIONAL REAR WEIGHT (IF EQUIPPED)
The rear weight is used to maximize
the traction of the tractor by increas-
ing the grip of the rear wheels when
using a heavy trailer or plow.
Max. load
27 kg x 10 Pieces (595
lbs)
