ITEM RX6030C RX6030 RX7030 RX8030C RX8030
Hydraulic system
3 Point Lift Control Type
Position, Draft,
Mixed Control
Standard remote
valve quantity
Rear remote hydraulic valve 2 (Port:4)
3-point hitch Category
Ⅱ
Max. lifting
capacity
24 in. (610 mm)
Behind
kg.f (lbs) 1,630 (3,594) 1,768 (3,898)
Lower link end kg.f (lbs) 2,075 (4,575) 2,256 (4,974)
PTO
Rear
Type Independent
P·T·O shaft SAE 1-3/8, 6 Spline
Speed (PTO rpm) 540 / 540E
Min. turning radius
(with one rear wheel
braked)
Agricultural
mm (in.) 3,110 (122.4) 3,370 (132.7)
Weight
(Incluiding cabin,
excluding front weight)
kg.f (lbs) 2,630 (5,798)
2,360
(5,203)
2,795 (6,162)
2,535
(5,589)
Max. Drawbar vertical load
kg.f (lbs) 750 (1,655) 900 (1,984)
Automation system
Auto P·T·O Std.
※
The specications are subject to change without notice.
