Single Speed Model
■
Dual Speed VFD Model (Body size B, C)
■
Dual Speed VFD Model (Body size D, E, F)
Inverter
Controller cover
Panel
Limit switch
Packing C
Braking resistor
Nameplate
Resistor cover
Interface board
Noise filter
Inverter
Controller cover
Braking resistor
Nameplate
Panel
Limit switch
Noise filter
Resistor cover
Interface board
Packing C
A
Product Structure and Names of Each Part
Controller cover
Panel
Limit switch
Packing C
