KITO ER2 Series User Manual

52
●
Hook suspendeed Type:ER2
Manual Trolley type:ER2SP/ER2SG
●
Motorized Trolley type:ER2M
Assembling (continued)
Chapter 1 Handling the Product
1
AssemblingChecking Power and Power Cable
■
Checking Power and Power Cable
• Check that the rating of the breaker satisfies the specification required by the electric chain hoist.
• Check that the source voltage satisfies the rated voltage of the electric chain hoist.
Failure to comply with this instruction may result in death or serious injury.
Mandatory
DANGER
Code
Wire size
(mm
2
)
Capacity of fuse and circuit breaker (A)
230V Class 400V Class
Single speed Dual speed Single speed Dual speed
ER2-001H/IH
1.25
5 5
5 5
ER2-003S/IS
ER2-005L/IL
ER2-003H/IH
10 10ER2-005S/IS
ER2-010L/IL
ER2-010S/IS
15 15 10 10ER2-016S/IS
ER2-020L/IL
ER2-020S/IS
2 20 30 15 15
ER2-025S/IS
ER2-032S/IS
ER2-050S/IS
Code
Wire size
(mm
2
)
Capacity of fuse and circuit breaker (A)
230V Class 400V Class
ER Single
MR Single
ER Dual
MR Dual
ER Single
MR Single
ER Dual
MR Dual
ER2-001H/IH
2
10 10
10 10
ER2-003S/IS
ER2-005L/IL
ER2-003H/IH
15
15ER2-005S/IS
ER2-010L/IL
ER2-010S/IS
20ER2-016S/IS
ER2-020L/IL
ER2-020S/IS
3.5 30 30
15 15ER2-025S/IS
ER2-032S/IS
ER2-050S/IS 20 20
■
Checking the Power

KITO ER2 Series Specifications

General

Control Voltage	24V
Duty Cycle	40% ED
Protection Class	IP55
Temperature Range	-20°C to +40°C
Type	Electric Chain Hoist
Frequency	50/60 Hz
Motor Insulation	Class F
Brake Type	Electromagnetic
Load Chain Grade	Grade 80
Ambient Temperature	-20°C to +40°C
Power Supply	3-phase
Lift Height	3 to 30 meters
Chain Falls	1 or 2
Voltage	200-240V, 380-480V
