KITO ER2 Series User Manual

37
• The each type of Chain Container has the capacity to store the specific amount of the Load
Chain. Use correct capacity of the Chain Container.
When storing the Load Chain of which amount exceeds the capacity of the Chain Container, it may result in death or
serious injury due to the flow over of the Load Chain from the Chain Container or defective operation of the electric
chain hoist.
Improper combination of the Chain Container and the electric chain hoist is very dangerous because of the possibility
of drop of the Chain Container.
The seal to indicate the capacity and lifting height is attached on the Chain Container. Check it before use.
• If the Chain Container is not assembled correctly, it may result in death or serious injury due to a
drop of the Chain Container or Load Chain, and malfunction of the Electric Chain Hoist.
Refer to the assembling instruction on the page 38 and assemble the Chain Container correctly.
Failure to comply with these instructions causes bodily injury or loss of property.
Mandatory
Assembling
• Only maintenance engineers or the personnel with expertise are allowed to assemble and
disassemble the electric chain hoist.
Assembling or disassembling of the electric chain hoist may result in death or serious injury.
Prohibited
■
Assembling Parts to Electric Chain Hoist
■
Preparation for Assembling
• Hang the electric chain hoist body size to facilitate the mounting of the Chain Container.
• Check that the stopper and the cushion rubber are mounted at the link third from the no load side of the Load
Chain (the end without the Bottom Hook).
■
Mounting the Chain Container
The three types of the Chain Container are provided: bucket made of plastic, canvas and steel
This manual describes the method to combine the plastic or canvas Chain Container with the body size of the electric
chain hoist. Refer to the separate “Mounting Manual of the Steel Chain Container" for the steel Chain Container.
• When storing the Load Chain into the Chain Container, put the chain end with no-load side first
and then store the rest of the Load Chain.
Failure to comply with these instructions causes bodily injury or loss of property.
Mandatory
CAUTION
Assembling Assembling Parts to Electric Chain Hoist
1
(to be continued)
DANGER
DANGER

KITO ER2 Series Specifications

General

Control Voltage	24V
Duty Cycle	40% ED
Protection Class	IP55
Temperature Range	-20°C to +40°C
Type	Electric Chain Hoist
Frequency	50/60 Hz
Motor Insulation	Class F
Brake Type	Electromagnetic
Load Chain Grade	Grade 80
Ambient Temperature	-20°C to +40°C
Power Supply	3-phase
Lift Height	3 to 30 meters
Chain Falls	1 or 2
Voltage	200-240V, 380-480V
