122
Product Structure and Names of Each Part
Appendix
Load Sheave
Pinion
Rotor
Stator
Key
Body
Gear case
Friction clutch
Load gear
Top Hook
Electromagnetic brake
Brake cover
Fan
Fan cover
Chain Guide A
Chain Guide B
Hub
Packing M
Packing B
V ring
Shaft retainer clip
Cushion rubber (Chain spring and limiting plate)
Bottom Yoke
Bottom Hook
Motor shaft
Shaft retainer plate
Oil seal
Controller cover
Packing G
Bearing bracket
Connection shaft
Lever pin
Lever pin spring
Limit lever
The structure inside the controller cover and
the names of each part are described
below.
A
Product Structure and Names of Each Part

Table of Contents

Other manuals for KITO ER2 Series

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the KITO ER2 Series and is the answer not in the manual?

KITO ER2 Series Specifications

General IconGeneral
Control Voltage24V
Duty Cycle40% ED
Protection ClassIP55
Temperature Range-20°C to +40°C
TypeElectric Chain Hoist
Frequency50/60 Hz
Motor InsulationClass F
Brake TypeElectromagnetic
Load Chain GradeGrade 80
Ambient Temperature-20°C to +40°C
Power Supply3-phase
Lift Height3 to 30 meters
Chain Falls1 or 2
Voltage200-240V, 380-480V
