Chapter 1 Handling the Product
Work Flow of Assembling and Installation
The contents of the work to assemble and install the product by the maintenance engineers and installer are described
from this page and after. To eliminate the redo work and for effective assembling and installation, please check the
following work flow first and then start assembling and installation work.
Model Check
AssemblingInstallation
Check after Installation
Hook Suspended Type (hoist only) Trolley Type
Installation of Hook Suspended Type (hoist only) (P57) Installation of Trolley Combination Model (P58 to 60)
Assembling Parts to Electric Chain Hoist (P37)
Checking Power and Power Cables (P52)
Combination with the Motorized Trolley (P42) Combination with the Manual Trolley (P47)
Motorized Trolley Type Manual Trolley Type
Connecting Cables Connecting Cables Connecting Cables
Preparation
Mounting the Chain Container
Lubrication on the Load Chain
Checking gear oil
Connecting Power Cable to the power
Mounting the Travel Rail
Mounting the Stopper
Power Cable layout of Electric/Manual Trolley Combined Model

Case for cable hanger

Case for T-shape/angle type hanger
Connecting Power Cable
to the power
Checking installation method
and place
125 kg~5 t

Connecting relay cable

Connecting the Power Cable

Connecting Push Button Switch Set Cord
125 kg~5 t

Connecting the Power Cable

Connecting Push Button Switch Set Cord
How to use the Oil Cap
(Only for the Friction Clutch with mechanical brake)
Checking the power

Checking the breaker ratings
Checking the Power Cable

Permissible cable length and size
Checking and Carrying Out “Check Items” (P61)
ER2M
ER2
ER2SG / ER2SP
Carrying Out Operational Check (P61)
Motorized Trolley Type (P55)
125 kg~5 t

Connecting the Power Cable

Connecting Push Button Switch Set Cord
Hook Suspended Type (hoist only) (P54) Manual Trolley Type (P56)
 Part replacement of the electric chain hoist
Checking the rail width of the motorized
trolley
Checking the number and position of
adjusting collars
Combination of the electric chain hoist and
the motorized trolley
Mounting the balance weight

Part replacement of the electric chain hoist
Checking the rail width of the manual
trolley
Checking the number and position of
adjusting collars
Combination of the electric chain hoist and
the manual trolley
1
Work Flow of Assembling and Installation

KITO ER2 Series Specifications

General

Control Voltage	24V
Duty Cycle	40% ED
Protection Class	IP55
Temperature Range	-20°C to +40°C
Type	Electric Chain Hoist
Frequency	50/60 Hz
Motor Insulation	Class F
Brake Type	Electromagnetic
Load Chain Grade	Grade 80
Ambient Temperature	-20°C to +40°C
Power Supply	3-phase
Lift Height	3 to 30 meters
Chain Falls	1 or 2
Voltage	200-240V, 380-480V
