Below, there are two more examples for the way of addressing assigned to the processor and
landing bus:
I: Full load
x.yy.z
C.48.1
x =
Location (P, C, L)
Car
y =
Address (0-63 for C and L)
48
z =
1-4 for Car and Landing
address 0-47
1
1-8 for Car and Landing
address 48-63
I: Reset inspection (Pit)
L.00.4
The input is on the bus, address
(slot) 0, port 4
I: Inspection on (Pit)
P.01
The input is on the processor
board.
