Kleemann GENIUS20 User Manual

120
MA06-03-1-01
Menu
Parameter
[Direct access]
Description
Default value
Value
Range
I:FC in floor side2
Definition of an input to activate the fire case
function in the landing on door side 2.
*FC in floor signal
Selection whether the fire signal is applied by an
N/C contact (=Y) or N/O contact (=N) on door
side 1.
NO
N.O./N.C.
I:FC end
Definition of an input to switch off/active fire
case.
T:Time to close
door(s)
Definition of the time span (seconds) after which
the doors absolutely have to be closed in case of
fire.
0
0-99 s
DS1 open mask
[CMD -> 7168 ->
OK]
Change to page 168 to define “DS1 open mask”
for door side 1. The activated landings allow an
evacuation in case of fire on door side 1. The
doors of a locked landing will not be opened!
For further information regarding this submenu,
check the corresponding chapter.
DS2 open mask
[CMD -> 7168 ->
OK]
Change to page 168 to define “DS2 open mask”
for door side 2.
1.I: Smoke
detectors D1
Definition of the first input, i.e. there are further
inputs to evaluate the smoke detectors of door
side 1 (Dynamic fire case control).
I: Smoke detectors
D1
Definition of an input to evaluate an extra
smoke detector at door side 1.
1.I: Smoke
detectors D2
Definition of the first input, i.e. depending on
the landings there are further inputs to evaluate
the smoke detectors of door side 2 (Dynamic fire
case control).
I: Smoke detectors
D2
Definition of an input to evaluate an extra
smoke detector on door side 2.
*Smoke detectors
sig.:
Selection whether the smoke detector signals
are applied by normally close contacts or
normally open contacts.
N.O./N.C.
Smoke dectectors
active: FC
Selection whether an active smoke detector is to
trigger a fire case.
NO
YES/NO
O:Acoustic signal
Definition of an output for acoustic signalling of
the active fire case function.
O:Text fire case
Definition of an output (pulse) for visual
signalling of the active fire case function.
O: Reach to target
Definition of an output to signal that the fire
evacuation floor is reached.
Ignore light curtain
Selection whether in case of fire the light curtain
are to be ignored. YES initiates the doors to be
NO
YES/NO
