Parameter
[Direct access]
Lift info
[CMD → 7176 →
OK]
Here you can enter general lift information. The
manufacturer is taken from the company code. Further
information can be entered. Currently the following
information is available:
Lift ID; Manufacturer; Street 1; Street 2; House number;
Postcode; City;
For further information regarding this submenu, check
the corresponding chapter.
Number of landings.
Note for groups:
All lifts of one group have the same number of landings.
It contains all the landings that can be reached by any lift
of the group.
Example: Lift 1 has B, G, 1, 2, 3, 4, 5 and lift 2 has G, 1, 2,
3, 4, 5, 6, 7 → number of landings = 9.
Number of door sides.
(1): one access
(2): two accesses
Number of call buttons in the landing.
(1): Single-button control
(2): Two-button control (upwards or downwards call)
Definition of the zone length in mm (= zone length Z1). A
number of calculations is based on the definition of the
rail length, which are required by the controller for the
shaft selection, e.g.
❑ speed measurement
❑ determination of landing distances (if
required, the pulse constant)
❑ determination of the emulated zone
length (Z1) if using the absolute
encoder. The position of the door zone
(Z2) magnets depends on this. Usually
Z2 is supposed to be 10 cm longer than
Z1 (5 cm upwards and 5 cm
downwards).
❑ determination of the monitored zone
to detect any unintended car
movement (UCM).
Definition of the maximum value of a step to level the car
in the landing.
VVVF (Inverter)
[CMD -> 7061 -> OK]
Asks whether a rope-traction lift is operated with
frequency inverter. By choosing “YES”, the frequency
inverter’s parameters are made visible. Press > to go to
pages with inverter parameters (page 061). For further
information regarding this submenu, check the
corresponding chapter.
