Parameter
[Direct access]
Definition of an output to signal the activation or
deactivation of car light.
Definition of an output for the travel signal.
Dividing door
[CMD -> 7009->
OK]
Query whether partition doors are available. If yes,
change to page 67 in order to parameterise those.
This setting is also available in Parameters - Doors.
Car fan
[CMD -> 7134->
OK]
Query whether a car fan is to be activated. If "YES",
change to the fan parameters page. For further
information regarding this submenu, check the
corresponding chapter.
Definition of an output to signal the out-of-order
state in the car.
Definition of an input for the full load signal; indicated
e.g. on the display in the car.
Definition of an input for the overload signal;
indicated e.g. on the display in the car.
Definition of an output to issue an acoustic signal.
Rings out in case of e.g. overload, fire emergency, ect.
Definition of two outputs to indicate the travel
direction (up/down). Display in the car on e.g. a
luminous indicator field.
O: Acoust. Signal
feedback
Definition of the output for acoustic
acknowledgement of, inter alia, call buttons.
Definition of two outputs to indicate the travel
continuation direction (up/down).
Determination of an output to signal that the door
will open.
Definition of an output address which determines
from which bit location the car position is to be
indicated. On the bus module page in the hand
terminal, the letter “A” illustrates the subsequently
necessary bits.
The car position is configured as follows:
“Yes” issues the car position in linear mode. The
remaining configuration parameters for this output
mode are automatically set to “No”.
