Kleemann GENIUS20 User Manual

109
MA06-03-1-01
Menu
[Direct access: CMD -> 7087]
Parameter
[Direct access]
Description
Default
value
Value Range
Fix floor
Definition of the fixed parking landing’s
number.
0
(=deactivat
ed)
0-max. landings
Main stop parking
Query whether the lift is to park in the main
landing.
NO
YES/NO
Decided by
ΚΜGroup
Query whether the distribution for parking
this system is to be made by the group
controller.
NO
YES/NO
T: Parking time(s)
Definition of the time interval necessary for
approaching the parking landing. When this
time has elapsed - after the last travel - the
lift goes to the parking position.
0-999 s
Door open in park
floor
Query whether the doors are to be opened
after having approached the destination
parking landing.
NO
YES/NO
