EVO-S, EVO-H MODULAR AIR HANDLING UNITS
OPERATION AND MAINTENANCE MANUAL
KLIMOR EVO 0120 1800 1800 120 10159 35557
KLIMOR EVO 5320 2400 1500 120 11261 39413
KLIMOR EVO 0720 2000 2000 120 12722 44528
KLIMOR EVO 0230 2800 1700 120 15163 53071
KLIMOR EVO 0530 3100 1700 120 16848 58968
KLIMOR EVO 0930 2400 2400 120
18713 65495
KLIMOR EVO 0040 3100 2000 120
20088 70308
KLIMOR EVO 0050* 3700 2000 120
24106 84370
KLIMOR EVO 0060* 3700 2400 120 29290 102514
KLIMOR EVO 0070* 4000 2500 120 33134 115970
KLIMOR EVO 0090* 4600 2800 120 43092 150822
KLIMOR EVO 0001* 4900 2800 120 45965 160877
KLIMOR EVO 0021* 5200 3100 120 54346 190210
*/ In the SE units sizes 0050-0021 the frame also appears un-
der the upper section
ΔP – available pressure 0÷1800 Pa
The selection of the air handling unit size is determined
by the velocity of air ow through lters, cooler, humidi-
er, pressure drop in the AHU and noise level. It is possible
to manufacture air handling units with dierent air ow
rate and pressure than those specied in Table 1. The
above-mentioned ow values apply to the AHU window.
For water heaters, do not exceed the speed of 4,5 m/s in the
exchanger window and for coolers 3,5 m/s.
2.2.2 Optimal parameters of heating, cooling and humidifying me-
diums
Table 2 Medium parameters
Parameters Unit Value
Evaporation temperature of the cooling gas ˚C +7
Temperature of the cooling water (glycol solution) at the
inow:
- minimum
- maximum
˚C
˚C
+2
+12
Maximum temperature of heating water:
- hot
- overheated
˚C
˚C
95
130
Water pressure for an electric steam generator MPa 0,1÷0,6
Recommended available pressure:
- for a water cooler with a control node
- for a water heater with a control node
MPa
MPa
0,05÷0,1
0,01÷0,05
2.2.3 Method of designation of KLIMOR EVO air handling units
KLIMOR EVO units are normally designated by an abbreviat-
ed code according to the designation in diagram 1.
Diagram 1 Abbreviated designation of KLIMOR EVO AHUs
1 2 3 4 5
VERSION:
KLIMOR
EVO-S
- KLIMOR
EVO-H
standard -
hygienic
SIZE:
5100, 3200, 5200,
0300,0400, 2500,
3500, 0600, 0700,
5800, 8800, 0010,
5010, 5310, 4410,
5610, 0020, 0120,
5320, 0720, 0230,
0530, 0930,0040,
0050, 0060**
0070**, 0090**
0001**, 0021**
AIRFLOW
RATE
V/100*
AVAILABLE
PRESSURE
ΔP/10*
VERSION
R – RIGHT-
HAND
SIDED L –
LEFT-HAND
SIDED
(*) airow rate rounded upwards, available pressure rounded
downwards
**) customised sizes of the units
EXAMPLE: KLIMOR EVO AHU version: standard right-hand
sided, size 0010, air volume 10000 m
3
/h, available pressure
500Pa.
KLIMOR EVO-S 001010050R
Full designation of the KLIMOR EVO AHUs includes addition-
al codes of the air handling sections.
Diagram 2 Extended designation of KLIMOR EVO AHUs
1 2 3 4 5
VERSION:
AIRFLOW RATE
AVAILABLE
PRESSURE STR.
SECTION
CODE:
acc. to the
Table No. 3
AD
REGULATING,
SHUT-OFF
AIR DAMPER
FC
ELASTIC
CONNEC-
TIONE
OPCJE
O - external
version
CS –
Control system
included
