Table 23 Parameters necessary for correct setting of the pump frequency converter
Glycol installation
symbol
Pump symbol
Cataloge
No.
Minimum motor
frequency Fz min
[Hz]
Maximum motor
frequency Fz max
[Hz]
Rated motor
power [kW]
Rated engine
speed [rpm]
Rated motor
current [A]
INST.GLKL.LE_HE 5100 CM1-2 A-R-A-E-AQQE 97516558 5 65 0,46 2820 2,2/1,2
INST.GLKL.LE_HE 3200 CM1-4 A-R-A-E-AQQE 97514257 5 65 0,46 2820 2,2/1,2
INST.GLKL.LE_HE 5200 CM3-5 A-R-A-E-AQQE 97516566 5 65 0,65 2820 3,1/1,8
INST.GLKL.LE_HE 0300 CM3-6 A-R-A-E-AQQE 96807027 5 65 0,65 2820 3,1/1,8
INST.GLKL.LE_HE 0400 CM3-6 A-R-A-E-AQQE 96807027 5 65 0,65 2820 3,1/1,8
INST.GLKL.LE_HE 2500 CM3-5 A-R-A-E-AQQE 97516566 5 65 0,65 2820 3,1/1,8
INST.GLKL.LE_HE 3500 CM3-5 A-R-A-E-AQQE 97516566 5 65 0,65 2820 3,1/1,8
INST.GLKL.LE_HE 0600 CM3-6 A-R-A-E-AQQE 96807027 5 65 0,65 2820 3,1/1,8
INST.GLKL.LE_HE 0700 CM3-6 A-R-A-E-AQQE 96807027 5 65 0,65 2820 3,1/1,8
INST.GLKL.LE_HE 5800 CM5-6 A-R-A-E-AQQE 98608252 5 65 1,5 2910 5,7/3.3
INST.GLKL.LE_HE 8800 CM5-6 A-R-A-E-AQQE 98608252 5 65 1,5 2910 5,7/3.3
INST.GLKL.LE_HE 0010 CM5-6 A-R-A-E-AQQE 98608252 5 65 1,5 2910 5,7/3.3
INST.GLKL.LE_HE 5010 CM5-6 A-R-A-E-AQQE 98608252 5 65 1,5 2910 5,7/3.3
INST.GLKL.LE_HE 5310 CM10-3 A-R-A-E-AQQE 96943353 5 65 2,2 2910 8,3/4,8
INST.GLKL.LE_HE 4410 CM10-3 A-R-A-E-AQQE 96943353 5 65 2,2 2910 8,3/4,8
INST.GLKL.LE_HE 5610 CM10-3 A-R-A-E-AQQE 96943353 5 65 2,2 2910 8,3/4,8
INST.GLKL.LE_HE 0020 CM10-3 A-R-A-E-AQQE 96943353 5 65 2,2 2910 8,3/4,8
INST.GLKL.LE_HE 0120 CM10-4 A-R-A-E-AQQE 98730017 5 65 3 2920 11/6,3
INST.GLKL.LE_HE 5320 CM10-4 A-R-A-E-AQQE 98730017 5 65 3 2920 11/6,3
INST.GLKL.LE_HE 0720 CM10-4 A-R-A-E-AQQE 98730017 5 65 3 2920 11/6,3
INST.GLKL.LE_HE 0230 CM15-3 A-R-A-E-AQQE 98715276 5 65 4 2940 13,2/7,65
INST.GLKL.LE_HE 0530 CM15-3 A-R-A-E-AQQE 98715276 5 65 4 2940 13,2/7,65
INST.GLKL.LE_HE 0930 CM25-3 A-R-A-E-AQQE 98667851 5 65 5,5 2940 19/11
INST.GLKL.LE_HE 0040 CM25-3 A-R-A-E-AQQE 98667851 5 65 5,5 2940 19/11
INST.GLKL.LE_HE 0050 CM25-4 A-R-A-E-AQQE 99205259 5 65 7,5 2920 24,2/14
4.14 CM.i, HPM.i, HPM.d and CM.d cooling systems
Cooling sets are intended for use in air conditioning and
ventilation systems with air cooling. The air to be processed
must be chemically inert, free of caustic, explosive sub-
stances and viscous and brous oily suspensions.
Cooling sets are an integral part of KLIMOR EVO modular
air handling units.
HPM.i and HPM.d type cooling systems are made as revers-
ible heat pumps. This allows for both heating and cooling
functions.
CM.i and CM.d are systems that work exclusively as a cool-
ing system.
HPM.i and CM.i systems are based on smoothly controlled
DC Inverter compressors and work on R410a refrigerant.
HPM.d and CM.d systems are based on Digital Scroll com-
pressors and work with R407c refrigerant.
Both types ensure smooth regulation of cooling capacity
and electricity demand.
For proper operation of the cooling system, the right
amount of air and its parameters are required.
The table below shows the minimum air volumes depend-
ing on the size of the AHU and the number of rows of ex-
changers occurring as condenser and cooler.
A larger number of rows allows to receive/give back a power
with less air. All data refer to the summer period (cooling op-
eration) and the outlet air temperature of 24°C due to less
favourable operating conditions
When the delivery of Klimor does not include the control
system, these are also the minimum air volume at which the
HPM/CM heat pump system work permit may be issued.
Table 25 Minimum air volumes required for HPM and CM refrigeration at full capacity
HPM.i ; CM.i
Unit size
System
symbol
Air ow rate
min. [m
3
/h]
Number of rows of exchan-
ger at the exhaust
0300 25 2400 6
0300 25 1400 8
0300 43 2400 8
0400 43 2000 8
0400 43 3500 6
0400 71 4000 8
2500 43 2500 8
2500 43 3300 6
2500 71 3600 8
3500 43 2500 8
3500 43 3300 6
3500 71 3600 8
0600 43 3100 8
0600 43 3800 6
0600 71 4300 8
