3.6.1 Setting of the inverters
Below you can see the inverter settings for controlling
a 0-10V signal from an external source for both types of
frequency inverters. Wiring of the drives according to their
OMM.
If the unit is delivered together with Klimor automatic sys-
tem, do not use these settings, only the information con-
tained in the OMM of automatic system.
Table 9. Basic parameters for programming the Danfoss FC 51 inverter. Settings for velocity
setting via 0-10V analogue signal
Parame-
ter no.
Name of the parameter Setting Unit
QUCK MENU I
120 Rated motor power According to the motor plate kW
122 Rated motor voltage According to the motor plate V
123 Rated motor frequency According to the motor plate Hz
124 Rated current According to the motor plate A
125 Rated motor velocity According to the motor plate RPM
129
Automatic adjustment
to AMT motor
On [2] */
302 Minimum value 15 Hz
303 Maximum value According to the unit data Hz
341
Accelerating time in sec.
min. to max. setpoint
30 sec.
342
Braking time in sec. min.
to max. setpoint
30 sec.
MAIN MANU
190 Thermal motor protection ETR Trip 1 [4]
315 Source 1 of the setpoint 1
316 Source 2 of the setpoint 0
317 Source 3 of the setpoint 0
412 Low motor speed limit 15 Hz
414 High motor speed limit i According to the unit data Hz
416 Torque limit in % 110 %
540 Relay function 6
610 Terminal 53 Low voltage 0.07 V
611 Terminal 53 High voltage 10 V
614 Terminal 53 Min. setpoint 15 Hz
615 Terminal 53 Max. setpoint 65 Hz
*/ When this parameter is set to [2], the PRESS HAND START appears
on the screen. After pressing the HAND START button on the panel,
the inverter performs an auto adjustment. When Auto Fit is com-
plete, press OK on the panel and the parameter is automatically set
to [0] and you can return to further programming.
Table 10. Basic parameters for programming the E800 Eura Drives inverter. Settings for
velocity setting via 0-10V analogue signal
Code
Name
Setting
Description
F106 Control Mode 6 PM synchronous motors (PMSVC)
F111 Max. frequency (Hz) Fz max Individual settings
F112 Min. frequency (Hz) Fz min Setting without motor overload
F118 Rated motor frequency (Hz) Plate related to F810
F200 Start command source 4 Keyboard + clamp + Modbus RS485
F201 Stop command source 4 Keyboard + clamp + Modbus RS485
F203 Main frequency source 2 External analogue - AI1
F300 Relay function 5 Alarm-free operation
F600 DC braking function selection 1 pre-start braking
F602
DC braking performance
before take-o (%)
20÷30
The higher the value, the more
eective the braking, but remem-
ber not to overheat the motor.
F604
Braking performance before
take-o (s)
15s
F607
Automatic selection of
dynamic parameters
0 disabled
F613 Inverter reset 0 disabled
F753 Type of thermal motor protection 0 Standard motor
F801 Rated motor power …kW Plate
F802 Rated motor voltage …V Plate
F803 Rated motor current …A Plate
F804 Number of the poles … Automatic setting [120*H118/F805]
F805 Rated motor velocity ...rpm. Plate
F810 Motor power frequency Plate related to F118
F800 Motor autotuning 1 Dynamic - recommended
