Section 12
Parts List
20413146
8-2012/Rev 12
12-10
Table 12-5
Pneumatic Valve/Actuator Assembly, Normally Open
10184760
Item
Part
Number Description Quantity Item
Part
Number Description Quantity
1 10189181 Valve Body 1 10189553 Actuator Assembly, Normally Open
2 10178697 Valve Seat 1 6 BV401184 Pneumatic Cylinder 1
3 20435636 Valve Stem 1 7 BV601184 Cylinder Head 1
4 10188233 Backup Ring, Brass 1 8 BV501184 Piston 1
5 20428052 Seal Assembly 1 9 10187250 Backup Ring, SST 1
10 10074714 O-Ring, 2.44 x 2.63 x .09 1
11 10074565 O-Ring, 2.25 x 2.38 x .06 2
05116017 Rebuild Kit
Includes Items 2, 3, 4, 5, 10 and 11
