Kollmorgen SERVOSTAR 400 Assembly & Installation

2.9.2 Connections
Function Connector type
Control signals Combicon spring terminal
Power supply Power Combicon
Motor Combicon
Resolver input SubD 9pol. (socket)
Incremental encoder input SubD 15pol. (socket)
PC interface SubD 9pol. (plug)
Encoder simulation, ROD/SSI SubD 9pol. (plug)
2.9.3 Recommended tightening torques
Connector Tightening torque
X1, X3, X6 0.3 Nm
X0 1.3 Nm
Earthing bolts 3.5 Nm
lower mounting bolt 3.5 Nm
2.9.4 Fusing
2.9.4.1 Internal fusing
Function
Auxiliary supply 24V 20 AM
Regen resistor electronical
2.9.4.2 External fusing
Function Fusible cutouts or similar
AC supply F
N1/2/3
16 A slow
24V supply F
H1/2
20 A slow
regen resistor F
B1/2
6 A slow
16 SERVOSTAR
®
400 Installation Manual
Technical description 07/05 Kollmorgen
