Kollmorgen SERVOSTAR 400 Assembly & Installation

6 Accessories
6.1 External PSU 24V DC / 5A
Technical data
Input voltage 120 / 230V
Input current 0.9 / 0.6A
Frequency 50/60Hz
Primary fusing 3.15AT
Output voltage 24V ± 1%
Max. output current 5A
Residual ripple <150mVss
Switching peaks <240mVss
Output fusing short-circuit proof
Temperature range 0 to +60°C
Mounting method
DIN-rail, vertical mounting
50mm free space required above and below the in
-
strument
Weight 0.75kg
SERVOSTAR
®
400 Installation Manual 63
Kollmorgen 07/05 Accessories
