1 General
1.1 About this manual
This manual describes the digital servo amplifiers of the SERVOSTAR 400 series.
In this manual you can find information about:
l
General Chapter 1
l
Technical description Chapter 2
l
Assembly / installation Chapter 3
l
Interfaces Chapter 4
l
Commissioning Chapter 5
l
Accessories Chapter 6
l
Transport, storage, maintenance, disposal Chapter 7
A more detailed description of the field bus interfaces and the digital connection to auto
-
mation systems can be found on the accompanying CD-ROM in PDF format (system
requirements: WINDOWS 95 or higher, Internet browser, Acrobat Reader) in several
language versions.
You can print out this documentation on any standard printer. A printed copy of the docu
-
mentation is available from us at extra cost.
This manual makes the following demands on qualified personnel :
Transport: only by personnel with knowledge of handling
electrostatically sensitive components.
Installation: only by electrically qualified personnel
Commissioning: only by qualified personnel with extensive knowledge of
electrical engineering / drive technology
1.2 Symbols used in this Manual
danger to personnel
from electricity
and its effects
general warning
general instructions
mechanical hazard
ð p.
see page (cross-refer
-
ence)
l special emphasis
Keys on the master:
U
press once : move up one menu item, increase number by one
press twice in rapid succession : increase number by ten
U
press once : move down one menu item, decrease number by one
press twice in rapid succession : decrease number by ten
U
U
hold right key pressed, and then press left key as well :
to enter number, Return function
SERVOSTAR
®
400 Installation Manual 5
Kollmorgen 07/05 General
