KOMPATTO KH0623 - Water Connection

5
KOMPATTO installation, use and maintenance manual
1. Installation
1.2. Positioning
g. 2
G 3/4"
-
+
+
-
1.3. Water connection
The water pressure must be of maximum (600
kPa)6bars.Ifthepressureofmainswateris
greater than this value, it is necessary to install
a pressure reducer upstream of the oven.
The minimum water pressure for the proper
operation of the oven must be above 3 bar
(onlyovenswithself-cleaning).
The oven has an inlet for softened water on the
rear bottom side of the oven. It will be on the
left side for ovens with 6 trays (g. 3)andto
the right for ovens with 10 trays (g. 4).We
always recommend installing a water softener-
descaler to bring the hardness of the water
entering the appliance to values between 6 °
and12°F(60-120ppm).
Beforeconnection,drainoffasufcientamount
of water to clean the pipe from metal residues.
Connect the "Water" pipeline to water mains
andinstallashut-offvalveandalteronthe
Make sure there is a minimum clearance of
50 mm on all sides between the oven and the
wall or the other equipment (g. 1).
All materials used for packaging are environ-
mentally friendly; they can be stored without
any risk or be disposed of according to local
regulations in force.
The oven should be levelled: to adjust the
height of the leveling feet proceed as shown in
g. 2, using a spirit level.
Unevenness or inclinations of a certain degree
can compromise the operation of the oven.
Remove the entire protective lm from the
external panels of the appliance, detaching it
slowly to remove all traces of adhesive.
Make sure that all openings and holes designed
for heat intake/discharge are not obstructed.
g. 3
