Kongsberg EA440 - Scope of Supply and Standard Delivery

10
392616/B
Scopeofsupply
Topics
Basicitemsprovidedwithastandarddelivery,page10
Basicitemsprovidedwithastandarddelivery
ToassembleacompleteEA440system,youwillneedasetofsystemunits.Themain
unitsrequiredareprovidedwiththestandarddelivery.
WhenyouunpackthepartsprovidedwiththeEA440delivery,makesurethatthe
followingitemsareincluded.
WBT
•1WBT
•1Powersupply
•1Powercable
•14–pinConXconnector—ForbatteryorUPS
•1Ethernetcable
•16–pinPCBconnector
•24–pinPCBconnectors
•1Panelcover
•2Cableglands–Forcableswithdiameter8-12mm
•3Cableglands–Forcableswithdiameter5.5-9.5mm
•3Blindplugs
•4Nuts
Transducers
Alargerangeoftransducersisavailableforthedifferentoperationalfrequencies.For
ordernumbers,seeourwebsite.
Transducers
Frequency(kHz)Beamwidth(degrees)Cablelength(m)
12–16/60
1216x1620
15–171517x1715
18–111811x1120
38–738
7x7
20
38–9389x920
EA440Installationmanual
