Note
Theuseof"U"shapedprolesandbulkheadsupportbracket(s)isoptional.
2Mountthe"U"shapedproles.
aDesign,manufactureandmounttheU-shapedsteelproles.
bMakesurethattheprolescanwithstandthefullweightofthecabinet.
cMaketherequiredmountingholestoacceptthebottomframe(withshock
absorbers).
dPositiontheprolesonthedeck,andmountthemusingboltsorwelds.
3Mountthebottomframe.
Thebottomframeisttedwithfourshockabsorbers.IfyouhaveusedU-shaped
proles,placetheframeontopofthese.
4Mountthebulkheadsupportbracket.
aDesignandmanufacturethebulkheadbracket.
bMaketherequiredmountingholestoacceptthetopshockabsorbers.
cPositionthebracketsonthebulkhead,andmountthemusingboltsorwelds.
5Mountthetopshockabsorberassembly.
aRemovethefourliftinglugs.
bMountthetopshockabsorberassemblyusingtwoofthesameholes.
cUsespareboltstoclosetheremainingliftinglugholes.
6Placecabinetinitscorrectpositiononthebottomframe.
aUsefourboltsthroughthebottomframetosecurethecabinet.
bMountthetopshockabsorberstothebulkheadsupportbracket(s).
7Fastentheearthstrap.
MountingthedrawersintheWBTCabinet
TheWBTCabinetcancontainmaximumsevencustomdrawers.Eachdrawerwillhold
oneWBTanditspowersupply.Thedrawerismountedinthesamewayasanyother
equipmentdesignedfor19"racksusingstandardtools.
Prerequisites
Youmustbeequippedwithastandardsetoftools.Thistoolsetmustcomprisethe
normaltoolsforelectronicandelectromechanicaltasks.Thisincludesdifferent
screwdrivertypes,pliers,spanners,acablestripper,asolderingiron,etc.Eachtool
mustbeprovidedinvarioussizes.Werecommendthatalltoolsaredemagnetizedto
protectyourequipment.
