Kongsberg EA440 - Installing the Transducer on a Blister or Drop Keel

392616/B
43
8Tightenthepackingnutonthecableglandproperlytoavoidleaks.
9Mountthetransducer.
10Sealthetopofthesteelconduittopreventwaterleaks.
11ConnectthetransducercabletotheWBT.
12Ifyourvesselwilloperateinwaterswithalotofmarinegrowth,considerapplying
athinlayerofanti-foulingpainttothetransducerface.
Installingthetransduceronablisterordrop
keel
Whenallthepreparationshavebeenmade,observethisprocedureforthemountingof
thetransducerIfrequired,additionalandmoredetailedproceduresmustbeprovidedby
theinstallationshipyard.
Prerequisites
•Thephysicallocationofthetransducerhasbeendetermined.
•Thesteelconduitsareinstalled.
•Asuitablefairingisdesignedandmounted.
Note
Wheneverrelevant,alldrawingsaswellasthephysicalinstallationofeachdevicemust
beapprovedbythevessel’ snationalregistryandcorrespondingmaritimeauthority
and/orclassicationsociety.
Thefollowingspecialtoolsarerequiredforthisinstallation:
•Torquewrenchforthemountingbolts
•Loctite270(permanenthigh-strengththreadlocker)
Context
Thisinstallationarrangementassumesthatyoucanaccesstheinsideoftheblisteror
dropkeeltomountthenuts.Ifthisisnotthecase,thetransducermustbemountedwith
threadedsteelrodsweldedtothebottomoftheblister.
InstallingtheEA440hardwareunits
