Cabledrawingsandspecications
Topics
Transducer,page57
Auxiliaryconnectorforsynchronization,page58
RS-232usedassynchronizationtrigger(inputoroutput),page59
Transducer
ForanEA440systemtheWBTcanhandleuptofourchannels.
ATransducers
BOptionaljunctionbox
CWBTtransceiver,connectorP1
DWBTtransceiver,connectorP2
EThecablescreenmustbeterminatedinthecablegland
Ifyouneedtosplicethetransducercable,westronglyrecommendtheuseofametal
junctionboxwithpropercableglands.Thecablescreenmustbeconnectedtothecable
glands.Thecablescreenandthejunctionboxchassismustnotbeconnectedtovessel
ground.Avoidgroundloops.Youmustusethesametypeofcableastheoriginal
transducercable,contactKongsbergMaritimeforadvice.
Cablelayoutandinterconnections
