Kongsberg EA440 - Auxiliary Connector for Synchronization

To Next Page

To Previous Page

392616/B

Auxiliaryconnectorforsynchronization

TheWBTisttedwithadedicatedsocketforauxiliaryinterfaces.

TheAuxiliarysocketontheWBTcanbeused

tointerfaceanexternalsynchronizationsystem.

ThesocketismadetotaConxall7-pin

Mini-Con-X

shieldedconnector.The

connectionsaremadeonpins2,3and5.The

connectorcanbeorderedfromthemanufacturer,

orpurchasedfromKongsbergMaritimeusingordernumber387563.

•Manufacturer:SwitchcraftConxall

•Manufacturer’swebsite:http://www.conxall.com

Pinnumber1234

PurposeFutureuse

Synchronization

Output

Synchronization

Input

Futureuse

Pinnumber

Purpose

DigitalgroundNotusedNotused

Minimumcablerequirements

•Conductors:4x0.5mm

•Screen:Overallbraided

•Voltage:60V

•Maximumouterdiameter:Denedbytheplugsand/orthecablegland

Ifyouneedtoinstallaverylongcable,increasethecrosssection.
