28
Setting
For the NORMAL, FAST, SUPER-FAST1 or SUPER-FAST2 setting
4-a-1. Select either [NORMAL], [FAST], [SUPER-
FAST1] or [SUPER-FAST2] and press
ENTER
key.
The MENU - MEAS - SPEED MODE - IN-
ND screen appears on the LCD.
This screen is used to determine whether the ND
filter built into the main unit is used or not.
4-a-3. Press
ENTER
key.
When the setting is confirmed, the MENU - MEAS -
SPEED MODE screen appears again on the LCD.
4-a-2 Press either or key to select
[AUTO], [OFF], [ONE] or [TWO]
*
.
* [TWO] can only be selected with CS-3000HDR.
If the “OVER” error message appears when set
to [OFF], set IN-ND to [ONE] or [TWO].
When measuring objects that have a wide range of luminance under the
adjusted measurement conditions (ex.
γ
measurement), set IN-ND to
[OFF], or to [ONE] or [TWO]. For [OFF] or [ONE]/[TWO], select [OFF]
when the upper limit luminance is up to 100 cd/m
2
, or [ONE] if it is 100
to less than 5,000 cd/m
2
, or [TWO] if it is 5,000 to 100,000 cd/m
2
.
For the MULTI-NORMAL or MULTI-FAST setting
4-b-1. Select either [MULTI-NORMAL] or [MULTI-
FAST] and press
ENTER
key.
The MENU - MEAS - SPEED MODE - MULTI-
INTEG screen appears on the LCD.
This screen is used for input of the integration
time in the MULTI INTEG-NORMAL mode
or the MULTI INTEG-FAST mode.
4-b-2. Press either or key to set a value.
Press key for a larger number.
Press
key for a smaller number.
The setting range of integration time
is from 1 to 16 seconds.
MEAS
MULTI-INTEG
INTEG TIME
01s
IN-ND AUTO
SPEED MODE
(
2/2
)
MEAS
MULTI-INTEG
INTEG TIME
10s
IN-ND AUTO
SPEED MODE
(
2/2
)
MEAS
NORMAL
FAST
SUPER-FAST1
SUPER-FAST2
SPEED MODE
(
1/2
)
MEAS
SPEED MODE
(
1/2
)
NORMAL
FAST
SUPER-FAST1
SUPER-FAST2
IN-ND
AUTO
ONE
OFF
TWO
MEAS
SPEED MODE
(
1/2
)
NORMAL
FAST
SUPER-FAST1
SUPER-FAST2
IN-ND
AUTO
ONE
OFF
TWO
To Next Page
