CONN ECTIN G H ARNES S
10' K.M. P/N 30-182
20' K.M. P/N 30-181
30' K.M. P/N 30-227
40' K.M. P/N 30-228
BK
RD
NOTE:ALL WIRES PASSING THROUG H 8-PIN CONNECTORS REMAIN THE
SAME COLOR (AS CALLED OU T IN THE CONNECTING HARN ESS).
NOTE:OTHER WIRES ARE LABLED AS: BK=BL ACK, BL =BL UE, RD=RED, PR=
PURPLE, GR=GREEN, OR=ORANGE, WT=WHITE, GY=GR AY
NOTE:ALL G ROUND/NEGATIVE WIRES ARE BLACK
.
TRIM SYSTEM ELECTRICAL DRAWING
(12
VOLT)
GR OU ND/NEGATIVE (BL AC K)
HOT/POSI TIV E (PURPLE)
GAUGE SENDER (RED)
LO W OIL INDIC ATION (GRAY)
TRIM/LIFT UP SOLENOID (BL UE)
TRI M AB LE (ORANG E)
TRIM/LI FT D OW N SO LEN OI D (GREEN)
LIFT AB LE (WHITE)
1
2
3
4
5
6
7
8
TRIM/
K.M. P/N 30-199
GAUGE
CONNECT TO (12VDC)
PO SITIVE S IDE OF
INS TRUMENT PANEL
ILLUMIN ATION C IR CUIT
CONNECT TO (12VDC)
PO SITIVE S IDE OF
INSTRUMENT PANEL CIRCUIT
BLPR
RD
RD
BL
GR
OIL RESERVOIR
BOTTLE + SWI TCH
K.M. P/N 30-992
TRIM/LI FT L IM IT
S WI TCH
K.M. P/N 30-959
TRIM/LI FT S END IN G
UN IT
K.M. P/N 30-959
TRIM/LI FT P UMP A SSEMB LY
K.M. P/N 30-200
POWER
RE L AY (UP)
POWER
RE L AY (DN)
1
2
3
4
1 2 3 4
5 6 TERM INAL S TRIP 1
TERM INAL S TRIP 2
5
6
7
8
1
2
3
4
PU MP MOTOR
CH ANGE O VER
RE L AY
CONNECT TO NEGATIVE/
GR OU ND SI DE O F 12VDC
CIRCUIT
CONNECT TO POSITIVE SIDE
OF 12VDC C IRCUIT (100
AMP)
DR AW I NG BY R .J.S.
JANUARY 2003
NOTE:COND UCTO RS (WIR ES) NO T S UPP LIED BY KONRA D M ARINE
GR BL
PR
OR
WT
BK
PR
BL
BKBK BK BK GY BK
5
6
7
8
1
2
3
4
1
2
3
4
5
6
7
8
NOTE:S.P.D.T. SWITCHES HAVE
MOMENTARY ACTION
"RED" L.E.D.
"RED" L.E.D.
"GREEN" L.E.D.
Up dated 2015
FIGURE C: TRIM SYSTEM ELECTRICAL DRAWING (12 VOLT)
