500 SERIES INSTALLATION MANUALJULY 2016 PAGE 45
10.7 Connect the eight (8) wire harness (run in Step 4.13) to
the eight (8) wire pigtail on the trim/lift control module.
NOTE: Bundle, cable tie and secure any excess harness.
10.8 Mount the module in the cutout area using the hardware
provided (if not done in Step 10.4 on page 44 in this
manual).
Step 10: Trim/Lift Control Module Installation (continued)
FIGURE 10F
FIGURE 10G
