500 SERIES INSTALLATION MANUALJULY 2016 PAGE 57
14.7 Determine an appropriate location and mount the power
steering uid reservoir.
NOTE: The reservoir must be mounted higher than, and
in close proximity to, the power steering pump.
NOTE: Be sure the reservoir is in an accessible location
for adding and checking uid.
14.8 Determine an appropriate location and mount the power
steering uid lter.
14.9 Determine the correct mounting location for the helm
assembly.
NOTE: Be sure there is adequate clearance under the
dash for the helm assembly and hoses.
NOTE: Be sure there is adequate clearance above the
dash for the steering wheel.
Lay out and cut/drill the appropriate area described by the
template provided from the manufacturer.
Step 14: Power Steering System Installation (continued)
FIGURE 14J
FIGURE 14H
FIGURE 14I
