500 SERIES INSTALLATION MANUAL JULY 2016PAGE 58
14.10 Install the helm assembly with the hardware provided.
14.11 Install the steering wheel with the hardware provided.
14.12 Determine an appropriate location and mount the steering
lock valve assembly.
NOTE: This should be in close proximity to the helm
assembly.
FIGURE 14L
Step 14: Power Steering System Installation (continued)
FIGURE 14M
FIGURE 14K
FIGURE 14N
