4.5. Electrical connection
4.6. Compressed air connection
Subject to errors and technical changes!
Labormaster Version 2.6.3 SW 2.2 from 03/2016 Page 27 of 82, March 1, 2016
Make sure that the socket you are using is easily accessible so that you can quickly unplug it if necessary. Lay the
connecting cable so that it does not become a tripping hazard. Do not let the connecting cable hang over the surface of
the device.
Electrical connection to 230 volts, 50 Hz; Plug in the power plug.
Setting the output air pressure: approx. 6 bar on the pressure control valve
• Pull the adjusting wheel on the pressure control valve, filter, water separator upwards and out of the
Insert the plug of the connection cable into the connection socket provided in the device.
• Connect compressed air 6 bar to the maintenance unit: connection piece for hose
Page - 27 -
Danger:
• Compressed air connection max. 6 bar. If the pressure gauge does not show 6 bar, set the maintenance unit to 6 bar:
Pull the black rotary handle vertically upwards out of the grid - turn it until the pointer points to 6 bar, - press
the rotary handle downwards to lock it into place. This grid is a safeguard against arbitrary adjustment of the
air pressure.
If the working pressure is significantly higher than 6 bar, the device can be damaged!
First check whether the voltage stated on the nameplate corresponds to your local mains voltage.
Inner diameter 8 mm or thread R 1/4".
Seal seam strength tester Labormaster HCT 3000
Operating instructions and technical description
Switch on the main switch on the device. The indicator light in the switch indicates operational readiness.
• Turn the adjusting wheel to the right until the desired output pressure (approx. 6 bar) is reached. The
Only use a fully installed and assembled sealing device.
Output pressure is displayed on the pressure gauge.
Insert the power plug into the socket.
Loosen the gearing.
• Turn the adjusting wheel to the left until it stops, then switch on the compressed air network.
D-73262 Reichenbach/Fils
Packaging systems
Ulmer Straße 51 – 53
Willi Kopp e. K
http://www.kopp-online.de
Fax +49.7153.9510-100
E-Mail: sales@kopp-online.de
Phone +49.7153.9510-0
Inh. Ludwig P. Goals
