5.Operation
Inh. Ludwig P. Goals
Fax +49.7153.9510-100
Packaging systems
Phone +49.7153.9510-0
Ulmer Straße 51 – 53
Willi Kopp e. K
http://www.kopp-online.de
D-73262 Reichenbach/Fils
E-Mail: sales@kopp-online.de
,
Sample dimensions above: width 10 to 60 mm, length 65 mm
Closing the roller clamp.
• Insert the flexible material at the bottom
6. Place the second test half with the sealing side down in the support clamp in which the first one is already held
Sample dimensions below: width 10 to 60 mm, length 110 mm
• To dispense with the deflection rod
5. The loose sample end around the deflection rod to the support clamp, without folding with light
Important when sealing flexible material against stiffer material:
Note: The clamping force on the support clamp is very low, so there is no impact on the measurement result.
• Insert the stiffer material at the top
Preload, lay. If there is a visible incorrectness, you can solve it by opening it again and
Seal seam strength tester Labormaster HCT 3000
Operating instructions and technical description
Page - 28 -
2. Set the main switch to “ON”. Winding roller (Figure 3 / device overview p. 19 (5)) is in the insertion position to
hold the sample half.
4. Close the clamp using the knurled wheel counterclockwise and tighten carefully.
3. Place the first sample half in the middle and at right angles to the roller, sealing side up.
8. Only now carefully tighten the upper clamp using the knurled wheel (counterclockwise
turn).
1. To hold the sample halves, use the knurled wheel to open both clamps ((Figure 3 / Device overview
p. 19 (4) and (5)) by turning them counterclockwise for the
winding roller, clockwise for the upper clamp,
Half of the sample lies, so that both samples lie exactly on top of each other.
Please take the deflection rod out of the device (see photos on the next page).
7. Slide the end of the second sample half into the upper clamp, above the winding roller.
5.1. Insert samples
Labormaster Version 2.6.3 SW 2.2 from 03/2016 Page 28 of 82, March 1, 2016
Subject to errors and technical changes!
