2. Description of the experiment
can be printed out and archived quickly and largely in a tamper-proof manner.
Therefore it is necessary to save the CSV file first. The first file (curve view, parameters and results) is then called
the same as the CSV file, but has the ending .bmp. In the second file (experiment description), the file name is supplemented
with “_2” and has the ending .bmp. The two files are automatically stored in the same directory as the CSV file.
Note: If
the curve has not yet been saved as a CSV file before you activate the screenshot, the saving process will
be canceled and the file functions will open. You then first have to enter a file name: Use the TAB key to move
the cursor (highlighted in blue) into the “Edit” input field and assign a file name. To do this, use the
connected PC keyboard. Confirm the file name with the ENTER key. You then need to save the Screenshot
function in the curve view
Two BMP files are always created:
.
Page - 46 -
The current curve, the most important sealing parameters and results as well as the test description can be saved in BMP
format as a screenshot (screen printout). The curves
For naming purposes, the system selects the last file name entered in the file functions.
Seal seam strength tester Labormaster HCT 3000
Operating instructions and technical description
Taste F3
5.3.17.6. Save curve function as a screenshot (screen printout).
Select one of your curves (p. 38). To save the screenshot (screen printout), you should first save the file in CSV format
(curve / save measurement data, p. 39) or at least assign a file name. Then switch to the curve view and press
1. Curve view with parameters and results
trigger again.
Important! Avoid saving multiple screenshots of the same curve. This can lead to file system conflicts.
D-73262 Reichenbach/Fils
Packaging systems
Willi Kopp e. K
Inh. Ludwig P. Goals
Phone +49.7153.9510-0
E-Mail: sales@kopp-online.de
Figure 20 / Screen printout
Ulmer Straße 51 – 53
Fax +49.7153.9510-100
http://www.kopp-online.de
Subject to errors and technical changes!
Labormaster Version 2.6.3 SW 2.2 from 03/2016 Page 46 of 82, March 1, 2016
