3.1. Device overview
Labormaster Version 2.6.3 SW 2.2 from 03/2016 Page 19 of 82, March 1, 2016
Subject to errors and technical changes!
Pair of sealing rails (replaceable).
Pos. assembly / designation / function
Central control panel with TFT color display.
Red-yellow main switch with emergency stop function: mains disconnection device for
switching the device on and off.
1
Behind the protective covers: Permanently heated pair of sealing jaws with built-in heating
cartridges and temperature sensors.
Page - 19 -
8
9
7
Pressure transmitter with attached force transducer for measuring the sealing force and
transmitting it to the PLC.
Seal seam strength tester Labormaster HCT 3000
Operating instructions and technical description
Rotating clamping and winding roller with eccentric tension for receiving the film samples.
Support with clamp for foil test strips.
5
Upper clamp with eccentric tension for holding the film samples.
6
Device for adjusting the closing force. A plate spring column is pre-tensioned using the
handle attached to the top of the device. This means that when the sealing rails meet, the set
sealing force is quickly achieved.
10 Two USB interfaces / One Ethernet interface.
2
3
4
Phone +49.7153.9510-0
Inh. Ludwig P. Goals
D-73262 Reichenbach/Fils
Packaging systems
Ulmer Straße 51 – 53
E-Mail: sales@kopp-online.de
Willi Kopp e. K
Figure 3 / Device overview
http://www.kopp-online.de
Fax +49.7153.9510-100
