Changing an effect Variation
4. Rotate the "A" double function edit control to select an effect Variation.
Some effects have other possible Variations. The Plate Reverb 1, for example, has
Room 1 and Hall 1 available as variations. When rotating the "A" edit control, for
effects with no variations, no change will occur.
Setting the effect parameters 5. Turn the double function edit control under any of the currently displayed
parameters to change Its value.
•
For fine adjustment of parameter values
1. Press the double function edit control under the parameter to be set. The indicator
of the double function edit control lights up and the parameter name is shown an
the display.
2. Use the UP/DOWN keys to make fine adjustments of the parameter value.
6. Selecting effect parameters on additional pages.
Most effects have parameters on additional pages, as indicated by an arrow up on
the top right of the display. Press the PAGE+ key to access these parameters.
Refer to the separate "EFFECTS AND PARAMETERS" for details on each effect
and it's parameters.
Turning Effects ON and OFF
Effects can be individually turned ON and OFF in three A1 modes. In the Play Mode and
Chain Edit Mode, by pressing the B-H double function edit controls, and in the Parameter
Edit Mode, by pressing the "A" edit control. When an effect is turned OFF. it's effect name
changes to lowercase letters.
Compare Key
During editing, it is possible to compare the current edit, with the original programmed
value, by pressing the COMPARE key. When you press the COMPARE key its LED
indicator lights up. When you press the COMPARE key again the LED turns off and the
edited parameter values are restored. If you make an edit while the COMPARE LED is
lit your current edits will be lost.
