5 Setting Foot Switch Functions
Foot switches connected to FOOT SWFTCH input jacks 1 and 2 on the rear panel can be
used to control the to I lowing I functions:
1. PROG UP (Program Up): While In Play Mode, advances the program number by 1.
2. PROG DOWN (Program Down): While in Play Mode, reverses the program number
by 1.
3. R-SP SPEED (Rotary Speaker Speed): Switches the speed (SLOW/FAST) of the
Rotary Speaker effect.
4. DYNAPAN TRG (Dynapan Trigger): Provides a manual trigger for the Dynapan
affect
5. HDLY REC (Hold Delay Recording): Switches the Manual Record I unction, in the
Hold Delay Effect, ON and OFF.
6. EXT CTRL (External Control): Switches the External Control function between
OPEN and CLOSE.
7. EFFECT 7: Switches the 7lh effect ON and OFF when the optional FC6 foot
controller is connected.
1. Press the Utility Mode key after the Global Utility Manu la displayed, then
press the "FT.SW" double function edit control.
The loot switch setting is displayed
2. Rotate the "B" double function edit control to select the function for Foot Switch 1.
3. Rotate the "E" double function edit control to select the function for Fool Switch 2.
4. After completing the foot switch assignments press the "H" [EXIT] double function edit
control to return to the GLOBAL UTILITY MODE.
The UP/DOWN keys can also be used to select the foot switch assignments.
52
