Appendices
226
Media
Load, Save, Utility, Make Audio CD, Play Audio CD
Data Filer functionality (Save and Load MIDI System Exclusive Data)
CD-ROM/R/RW (UDF Format read/write), Record & Play audio CDs (CD-DA), ISO9660 Level 1
WAVE file editing functionality
CD-ROM/R/RW can be used if a commercially-available USB drive is connected.
Controllers
Pads 1–8
Velocity-sensitive drum pads and chord triggers.
PAD MODE switch - selects velocity-sensitive or fixed-velocity operation,
CHORD ASSIGN switch
Control Surface
CONTROL ASSIGN
Switches
MIXER (T1–8, T9–16, INPUTS), REALTIME CONTROL,
EXTERNAL, TONE ADJUST, KARMA
RESET CONTROL Switch
8 Switches
MIXER: PLAY/MUTE (SOLO)
REALTIME CONTROL: IFX1–5, MFX1, MFX2, TFX on/
off
EXTERNAL: External mode. External MIDI control.
TONE ADJUST: Control the Tone Adjust functions
KARMA: KARMA control
8 Sliders
MIXER: Volume
REALTIME CONTROL: Realtime modulation
EXTERNAL: External mode. External MIDI control.
TONE ADJUST: Control the Tone Adjust functions
KARMA: KARMA control
* In External mode, the eight sliders, eight switches, and eight pads can be
used as MIDI controllers. 128 setups can be stored. (102 are preloaded. These
allow you to control software synthesizers or DAW software.)
Drum Track Switches = ON/OFF
KARMA
Switches = ON/OFF, LATCH, MODULE CONTROL (Master/A/B/C/D), SCENES 1/
5–4/8
X–Y control Switches = X–Y MODE, HOLD, MOTION
User Interface
Display
5.7 inch Touch View Color Graphical Interface
Color 320 x 240 pixel display, X–Y control function
MODE Switches = COMBI, PROG SEQ, SAMPLING, GLOBAL, MEDIA
Value Controllers
Switches = q/u, 10-key numeric keypad, -, (.), ENTER, COMPARE, VALUE
Slider, VALUE Dial
BANK Switches = I-A…G, U-A…G
SEQUENCER Switches = PAUSE, REW, FF, LOCATE, REC/WRITE, START/STOP
SAMPLING Switches = REC, START/STOP
TEMPO Switches = TAP TEMPO, TEMPO Knob
Other Switches = PAGE SELECT, EXIT, VOLUME MAIN Slider, display contrast
Common specifications
Frequency response 20 Hz–20 kHz ±1.0 dB 10 kΩ load
THD+N 20 Hz–20 kHz 0.08 % 10 kΩ load (typical)
Audio Outputs
Analog
AUDIO OUTPUT
(MAIN) L/MONO, R
AUDIO OUTPUT
(INDIVIDUAL)1, 2, 3, 4
1/4" TS (Mono), unbalanced, Master Volume slider controls only L/Mono and R
Output Impedance 1.1kΩ stereo; 550Ω mono (L/Mono only)
Nominal Level +4.0 dBu
Maximum Level +16.0 dBu
Load Impedance 10 kΩ or greater
Signal to noise ratio 90 dBu (typical)
Dynamic range 91 dBu (typical)
Headphone output
1/4" TRS (Stereo), Master Volume slider (link with Main output L/Mono)
Output Impedance 33Ω
Maximum Level 32+ 32 mW @33Ω
Digital
Optical S/P DIF
Format: 24 bit, S/P DIF IEC60958 EIAJCP-1201
Sample Rate: 48 kHz
Digital output of the same signals as AUDIO OUTPUT (MAIN) L/Mono, R
(Option) EXB-FW
6 channels, 24-bit, 48 kHz Sample rate
Digitally output the same signals as AUDIO OUTPUT (MAIN) L/Mono, R and
AUDIO OUTPUT (INDIVIDUAL) 1–4
